| Tunnel #14 |
East portal of Tunnel #14
 |
 |
West portal of Tunnel #14
ICC Valuation Report
Statement showing property changes from September 1, 1926, to December 31, 1927 |
||||||
line |
Character of property and description |
Date |
Units |
Number of |
Cost/unit |
Total |
| 1 | Account No. 5 Title Tunnels and Subways | |||||
| 2 | Tunnel No.14 MP 551.8 Single Track Driven | |||||
| 3 | Total Length 2121ft. (sta. "K" 1070+31 to "K" 1049+10) | |||||
| 4 | Lined Length concrete-226 ft. per plans 18653 & C.S.347 | |||||
| 5 | Lined Length timber-2098 ft. | |||||
| 6 | Two concrete portals, plans 18247,40613 & 40615 | |||||
| 7 | Excavation-solid rock | Cu Yd | 41,638 | 3.70 | 154,061 | |
| 8 | Excavation-solid rock (invert) | " | 155 | 2.50 | 388 | |
| 9 | Overhaul | Cu Yd Sta | 36,286 | .0125 | 454 | |
| 10 | Portal backfill-common | Cu Yd | 52 | .24 | 12 | |
| 11 | Portal backfill-Loose rock | " | 23 | .49 | 11 | |
| 12 | -Lining- | |||||
| 13 | ...Reinforced concrete | 1926 | " | 822 | 13.00 | 10,686 |
| 14 | ...Plain concrete | " | " | 403 | 11.50 | 4,635 |
| 15 | ...Plain concrete (invert) | " | " | 112 | 11.50 | 1,288 |
| 16 | ...Timber-untreated fir | " | m.b.m. | 844.621 | 40.00 | 33,785 |
| 17 | ...Timber-Redwood | " | " | 18.170 | 45.00 | 818 |
| 18 | Packing-cordwood | " | cord | 996 | 7.00 | 6,972 |
| 19 | Reinforcing bars | " | lbs. | 72,476 | .04 | 2,899 |
| 20 | Iron | " | " | 6,030 | .05 | 302 |
| 21 | Creosote paint | " | gallon | 589 | .70 | 412 |
| 22 | Tunnel Sign-C.S. 9 | " | Each | 2 | 1.00 | 2 |
| 23 | Pump fire extinguisher (5 gallon Pyrene) | 1927 | " | 2 | 20.00 | 40 |
| 24 | Patrol Fire (2 1/2 Gallon) | " | " | 1 | 10.50 | 11 |
| 25 | Fire Ladders 24 ft. | " | " | 2 | 6.00 | 12 |
| 26 | Fire Ladders 16 ft. | " | " | 1 | 4.00 | 4 |
| 27 | Fire barrels & covers-concrete | " | " | 4 | 5.00 | 20 |
| 28 | Fire buckets-metal, cone shaped | " | " | 12 | .25 | 3 |
| 29 | Axes, single bitt | " | " | 4 | 1.00 | 4 |
| 30 | ..........Total | $303,497.35 | ||||
| 31 | ..........Interest during construction | $16,625.33 | ||||
| 32 | ..........Final | $320,122.68 | ||||
